Diesel Common Rail Injector Test Bench with 0-2400 Bar Rail Pressure 5 Bar Precision and Full Automatic Control

MOQ : 1

Price : 3800

Model NO. : JZ-2000

Power : 3-Phase 4-Wire 380V 50/60Hz

Rail Pressure : 0-2400 Bar

Filter Precision : < 5 Um

Fuel Temperature : 38-42 ′c

Tank Volume : 18 L

Net Weight : 330 Kg

Rail Pressure Precision : 5 Bar

Specification : 1350*980*1560 mm

Motor Power : 22 KW

Output : 5.5 KW

Speed : 0~1450 RPM

CR Pressure : 0~2400 Bar

Gross Weight : 330 kg

Packing Size : 1350×980×1560 mm

Contact Now

Product Introduction

JZ-2000 common rail injector test bench adopts full automatic control, which can conveniently repair and test Euro-3, Euro-4 injectors.It can test thousands of injectors. The experimental data are complete.
Diesel Common Rail Injector Test Bench with 0-2400 Bar Rail Pressure 5 Bar Precision and Full Automatic Control

Diesel Common Rail Injector Test Bench with 0-2400 Bar Rail Pressure 5 Bar Precision and Full Automatic Control

Functions Description and Testing Scope

1. Test piezoelectric injectors

2. Test common rail injectors

3. Real-time display oil injection/return curve

4. Gear flow sensor

5. Flow sensor lineaar calibration

6. Flue tank oil level limit alarm

7. Remote software upgrade,data update

8. Test oil automatic heating /cooling comtrol

Product Details

1. Motor power is 22 KW

2. Air-cooled heat dissipation kit

3. Metering valve detect the fuel flow

4. Imported flow sensor from Germany

5. Equipped with genuine DRV

6. Equipped with genuine CP3 pump

7. Equipped with genuine common rail tube

8. Oil tank (including heating,refrigeration,liquid level detection,temperature detection)

9. Short-circuit protection, ground protection, over-pressure protection during the testing

10. Equipped frequency converter to achieve testing function under different speed conditions

11. Equipped precise filter before flow sensor, which can effectively keep the sensor clean and extend the flow sensor usage life

Software Advantage

1. Many language interfaces can be switched

2. Datas are from the orginal equipment of EPS708

3. Data are calibrated from by the latest injectors

4. More than 3000 test data used for different brands injectors calibrations

5. Data backup, system software and database upgrade free charge all the time

6. Automatic testing the fuel quantity of all working conditions, automatic generate report after testing

7. Automatic test injectors under different working conditions, automatic analysis results, and generate report after testing

8. Intelligent algorithm is used to automatically calibrate the fuel quantity of the new injector, and generate reports after testing

Technical Parameters

Technical Parameters
Output	5.5 KW
Power	3-Phase 4-Wire 380V 50/60HZ
Speed	0~1450 RPM
CR Pressure	0~2400 Bar
Rail Pressure Precision	±5 Bar
Tank Volume	8 L
Fuel Temperature	40±2ºC
Filter Precision	< 5μm
Gross Weight	330 kg
Packing Size	1350×980×1560 mm
Speed Control Model	Converter Control
Temperature Control System	Air Conditioning Heat Dissipation
Nozzle Sensor	Imported Original Elliptical Type Flow Sensor
Language	English, Spanish, Russian,etc
Material	Metal Plate
Painting	Powder Painting, Durable
Color	Green (can be customized)
